Summary of "CPC-Choke-Trim" by Carter Process Control GmbH

Overview

  • Title: CPC-Choke-Trim
  • Author: Carter Process Control GmbH
  • Date: April 8, 2013
  • Subject: Engineering and Design of Severe Service Choke Valve Trims

Key Features

  • JACK Trim: Joint Adverse Carbide Knowledge Trim, a patented design in severe service choke valve trims.
  • Materials Used:
    • Trim, Plug, and Seat Ring: Solid Tungsten Carbide with 6% cobalt (1-3 micron WC).
    • Stem: Duplex (F51), Inconel, or other materials as required.
  • Manufacturing: Without brazing, EDM, or erosion, enhancing trim properties and operation.

Benefits

  • Increased Process Security:
    • ISO Certified manufacturing and a 12-month international warranty.
    • Fast response with unique methods for rapid turnaround.
    • Over 25 years of experience in Control and Choke valve market.
  • Unique Production Methods:
    • Fast and innovative production techniques.
    • Cost savings and increased trim life.
    • Best in industry delivery standards.
  • Versatility:
    • Engineered to fit any valve manufacturer's body.
    • Suitable for new projects or retrofitting existing valves.

Advancements

  • Advanced Manufacturing Techniques:
    • Reduced time and cost, approximately half of other manufacturers' lead times.
  • Performance Value and Customer Service: Emphasized by CPC.
  • Direct Replacements: For Disk Stack technology in Severe Service Choke Control Valves.
    • Features include 100% interchangeability, highest grade materials, European manufacturing, and superior process security.

This summary provides a concise overview of the CPC-Choke-Trim document, focusing on its key aspects and innovations in choke valve trim design.
